Biomass Burner with clean and safe heat 1.5Million Kcal/h for grain dryer
Biomass burner is the company for the use of renewable resources, energy saving development of a new model. This model has biomass husk generator, coarse bran feeder, ash and smoke removal system, etc., each step is automatic control, the temperature can be accurately controlled at ±1 °C. The structure design is reasonable, the technical performance indicators have met the requirements of the plan, the series of bran furnace dryer, the use of biomass bran as fuel, save energy and reduce costs.
Detailed Parameters
Parameter name | Value |
Thermal power KJ/h | 1,500,000 |
Combustion Type | Suspension |
Heat exchanger method | Indirect heating |
Power | 17.55 kw |
Heat efficiency | ≥80% |
Husk Consumption | 220~550 kgs/h |
Ash Discharge | 40-95 kgs/h |
Number of dryers heated | 5-6 sets |
Fuel | Paddy Husk,Sawdust and other Bio Fuels |
Dimension L×W×H(mm) | 5900*6430*8520 |
